QT Programming – Assignments

Objectives:

Create an application which allows to display/select a color. Read through the existing code template, first. This time we create a widget by specializing QWidget. Our own color selection dialog is already laying out the UI elements.

Your job will be to implement the actual application logic using Signals and Slots.

Example:

• Create an application as shown in the sample Output for Qt Programming assignment 1:
  • Clicking on “Select Color” updates label with color’s name.
• Hints
  • QColorDialog::getColor() to fetch a color
  • QColor::name() to get the color name
• Optional
  • In QColorDialog, honor the user clicking “cancel”, and provide it with
  • the current color to start from.
  • Set the selected color as the label’s background
  • Hint: see QPalette
  • Hint: see QWidget::setAutoFillBackground()

Implementation Steps

• Implement the slot: Ask the user for a color
  1. Declare the method in a “private slots” section.
  2. Use QColorDialog::dialog() to fetch the color name.
  3. Override the window background color of the label using the color chosen by the user.
• Connect signals and slots
  • Connect the button’s pressed() signal with your slot.

Sample Execution / Output:

Test Case 1:

Test Case 3:

Objectives:

Create a slider widget, which contains a QSlider and a QLabel. Your slider widget shall be source compatible with QSlider. Your job will be to implement the actual application logic using Signals and Slots. Source compatibility is not only based on class methods, it includes also Signal and Slots.

The main.cpp code is there to test your slider functionality.

• Implement custom slider
  • API compatible with QSlider
  • Shows current value of slider.
• To create custom slider for Qt programming assignment 2
  • use QSlider and QLabel
• To test slider
  • cpp provides test code
  • QLCDNumber is part of test code

Implementation Steps:

1. Lookup QSlider documentation and the provided methods and Signals and Slots.
2. Implement the slider widget. It shall present a QSlider with a QLabel. The QSlider and QLabel shall show the value set on your slider widget.      When the user slides the QSlider, the right signals shall be emitted from your slider.

Sample Execution / Output:

Test Case 1:

Test Case 2:

Objectives:

• Tasks

Start: Create a window, which has three buttons (“One”, “Two”, “Three”) layered out horizontally for Qt programming assignment 4

Note: If you want to have a group title use QGroupBox

Exercise 1: Stretch 2-1-1

• Change the stretch of the buttons to
• one: 2
• two: 1
• three: 1
• •

Exercise 2: Find this stretch

• From the picture try to find the correct stretch for the buttons

Exercise 3: Stretch at the end

• remove all stretches
• add a stretch of 1 at the end of the layout
•

Exercise 4: Stretch the middle

• remove all stretches
• add a stretch of 1 between the buttons
•

Exercise 5: Make all buttons vertical expanding

• remove all stretches
• find all buttons: hint use QObject::findChildren
• change each buttons size policy to expand vertically
•

   Optional Tasks:

• Make buttons resize vertically when making the window higher.

Sample Execution / Output:

Test Case 1:

Objectives:

• Create a reusable component, which allows the user to choose a file (or directory) from a file dialog. The file shall be displayed in a line edit.
• Tasks

The file chooser has 2 modes:

• File Mode
• Directory Mode
• •

Hint : Make sure you have a nice designed API, which utilizes also Qt SIGNAL&SLOT mechanisms.

Sample Execution / Output:

Test Case 1:

Objectives:

• In this lab we will walk through the process of creating a custom widget. The discrete compass widget allows the user to select one of the main directions: North, West, South, East. The changes shall be propagated to the outside world.

  The compass panel is our test environment to test our compass class. It currently contains QLabels as placeholders for your compass.

  Note: The directions are represented by widgets of type QPushButton.

Tasks:

• Think about a possible API to set the direction of the compass.
• Think about how to notify other widgets about changes of direction.
• Change direction programmatically
• Get informed when direction changes
• Implement the compass widget
• Test the compass in the compass panel

Hint: For grouping buttons you can use the QButtonGroup (see setExclusive ())

Optional Tasks for Qt programming assignment 6:

• Add direction None
• Select direction with the keyboard

Sample Execution / Output:

Test Case 1:

Test Case 3:

Objectives:

• Create a text editor with load, save, quit about and About Qt

  Note: A QPlainTextEdit serves for editing the text.

Optional task for Qt programming assignment 8:

• Show whether the file is dirty
• Ask the user whether to save if file is dirty when application quits
• Make sure also to asks when window is closed via window manager
• Show the cursor position in the status bar
• Position is determined by cursors block and column count
• Add printing support.

See Printing with Qt Documentation

Sample Execution / Output:

Test Case 1:

Test Case 2:

Objectives:

Please create a form to order a product. The order comprises of a name, price, quantity and a total.

Requirements:

• The price can be a QSpinBox
• The quantity and total fields can be QDoubleSpinbox
• The total field should be read-only
• When the user changes the quantity or price the total price should be updated accordingly.
• Please use Qt Creator and Qt Designer.

Note: As usual the dialog should also have an ok + cancel button which will close the dialog and a proper dialog title.

Sample Execution / Output:

Test Case 1:
